Zyxel MES 3500-24F 24-port FE Fiber L2 Switch with Four GbE Combo Port

(0) 0 Reviews 0 Orders 0 Wish listed

Product Code: 150720

Key Features

Model: Zyxel MES 3500-24F
Policy-based QoS optimizes multi-service quality
Multilayer-aware
16K MAC address table
IPv6 management support

AED25,000.00 ~~AED26,000.00~~

Quantity :

Quantity:

Total price :

(Tax : )

Overview
Reviews

Specification

Main Feature
Type	ROHS Switch
Port	Total port count: 24 Dual-personality GbE ports: 4
Network Standard	IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-Tx Ethernet IEEE 802.ab 1000BASE-T Ethernet IEEE 802.3z 1000BASE-X IEEE 802.3x flow control IEEE 802.1d spanning tree protocol IEEE 802.1w rapid spanning tree protocol IEEE 802.1s multiple spanning tree protocol IEEE 802.1p class of service, priority protocols IEEE 802.1Q VLAN tagging IEEE 802.1X port authentication IEEE 802.3ad LACP aggregation IEEE 802.3az Energy Efficient Ethernet (EEE)
Transmission Method	Store and Forward
Data Transmission Rate	Switching capacity (Gbps): 12.8 Forwarding rate (Mpps): 9.6
MAC Address Table	16 K
Environment	Operating- Temperature: 0°C to 50°C/32°F to 122°F Storage- Temperature: -40°C to 70°C/-40°F to 158°F Humidity: 10% to 90% (non-condensing)
Hardware Features
Interface	Qty: 24
Power Supply	Input Voltage of AC: AC Power input (100V~240V) Input Voltage of DC: -37 to -72 V DC Maximum Power Consumption (Watt): AC=14, DC=14
Dimensions (L x W x H)	440 x 200 x 44.5 mm
Weight	2.6 Kg
Manufacture Warranty
Warranty	1 Year

Description

Zyxel MES 3500-24F 24-port FE Fiber L2 Switch with Four GbE Combo Port

Consistent service quality and reliable connecting ability in a converged network is the key for Carrier to connect and satisfy customers; therefore the ability to control traffic flow and set traffic policy becomes more critical than ever. The Zyxel MES3500 series offers wire-speed flow control that classifies and prioritizes the incoming packets according to the predefine QoS policies that meet the requirements of service providers. In terms of classification, the Differentiated Services Code Point (DSCP) field and the 802.1p Class of Service (CoS) field are identified to assess the priority of incoming packets. Classification and reclassification can be based on criteria as specific as rules based on IP, MAC addresses, VLAN ID, or TCP/UDP port number. For bandwidth management, the MES3500 series provides 8 priority queues per port for different types of traffics, allowing service providers to set policy-based rate limitations that take full advantage of constrained network resources and guarantee the best performance. Avoiding subscribers affecting each other on a shared network or shared device is a major concern for service providers. The Zyxel MES3500 series offers a complete set of security features to protect user data while administrating the traffics. Port security provides the ability to deny unauthorized users from accessing the network. Moreover, the 802.1X feature cooperating with RADIUS is useful to prevent unauthorized access based on username and password (or other credentials) and acts as powerful access control for converged networks with mixed wired and wireless access. The MES3500 series provides a multilayer (L2/L3/L4) ACL suite of sophisticated policy-based control mechanisms that enables service providers to deploy easily based on actual network environment needs via a Web GUI or command-line interface to prevent abnormal or illegal access. The policies can be defined to deny packets based on source and destination MAC addresses, IP addresses, or TCP/UDP ports. A quick recovery and round-the-clock network are vital for service providers to establish a robust network. The MES3500 series provides comprehensive features to make sure the network is well operated. The IEEE 802.3ad Link Aggregation feature reduces network downtime by providing redundant paths and bandwidth aggregation to critical connections, while IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) and IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) allow immediate recovery from failed connections by sending packets via the backup link. The enhanced digital interface allows real-time access to the device operating parameters, and it includes optional digital features such as soft control and monitoring of SFP I/O signals. In addition, the MES3500 series fully incorporates the functionality needed to implement digital alarms and warnings from fault isolation and failure prediction tasks as well as component monitoring features, among others. With the digital diagnostic monitoring interface, the MES3500 series enables users to easily detect packet loss from transceivers and aging cables; therefore users can not only avoid troubles such as unstable networking services but also boost productivity significantly. As Zyxel considers IPv6 management features as a future trend, complete IPv6 host management capabilities are added to the MES3500 series for guaranteed IPv6/4 migration and future-proof expansion. Itâ€™s not only beneficial for high-density Fast Ethernet deployments but also capable of preventing investment loss and therefore perfectly suitable for both network cores and edges.
